Brushless DC electric skateboard motor 6374 190KV 3500W 12S 8Nm BLDC Motor with Hall Wire ,round /D shaft optional Battle Hardened for Electric Bicycle, Scooter
Electric Skateboard Motor 6374 kit assembly:
- KV: 140/190KV
- Max Power: 3500Watts
- Max Current: 85 Amps
- Max Volts: 12S
- Max Torque: 8Nm
- Motor Resistance: 0.05Ohm
- Recommend ESC: 3-12S 50A
- The number of pole: 14
- Net weight: 980g
- Motor wire:12AWG
- Shaft size : 8mm/10mm
- The screws used for the motor are M4 metric bolts. Using our motor mounts, we recommend using M4 Socket Cap bolts.
- Screws to mount the motor are not included with the motor.
- If you choose round shaft motor, shipping includes the key for the keyway
- If you choose the shipping comes with pulley, will come with 8mm steel material pulley.
The Flipsky logo is in different places, will be shipped randomly.
Electric Skateboard Motor 6374
8MM Round Shape Shaft Drawing（108mm length）:
Electric Skateboard Motor 6374 10MM D-Shape Shaft Drawing(99 mm length）:
